GATTA-Cells NIR

GATTA-Cells NIR GATTA-Cells NIR

The GATTA-Cells NIR supplies you with high-quality standard cell slides with a labeled target in the near infrared (NIR) region. They are a perfect match for the new ZEISS LSM 980 with Airyscan 2 microscope.

Ready-to-use GATTA-Cells NIR slides contain fixed and stained huFIB cells for fluorescence imaging with labels in the region between 358 nm and 750 nm.

Currently we are offering one version:

GATTA-Cells 4C NIR

  • Multicolor huFIB cells displaying 4 colors
  • Nucleus: DAPI
  • Mitochondria: Tom20 with Alexa Fluor 488
  • Actin: Alexa Fluor 647
  • Microtubules: α-Tubulin with Alexa Fluor 750

GATTA-Cells are embedded in ProLong Diamond and show high photo stability with shelf lifes of at least 6 months (storage at 2-8 °C).

product properties of GATTA-Cells NIR

Type GATTA-Cells 4C NIR
Cell type huFIB
Fluorophores DAPI, Alexa Fluor 488, Alexa Fluor 647, Alexa Fluor 750
Embedding media ProLong Diamond
Labeling Intercalator, TOM20, Phalloidin, α-Tubulin
Level Beginner
Price 350,-€

Beginner: Samples to check the basic functions of your microscope. Easy to resolve, also for beginners in the field of super-resolution microscopy.

Advanced: Samples to optimize the settings of your microscope. Advanced experience is necessary in order to resolve the nanorulers.

Expert: Samples which demand perfectly aligned microscopes and very experienced users which are able to optimize acquisition and data evaluation.

fluorophore properties

 Fluorophore Our notation
Excitation / nm
Emission / nm
Alexa Fluor 750 NIR 749 775
Alexa Fluor 647 R 650 665
Alexa Fluor 555 Y 555 580
Alexa Fluor 488 B 488 525
DAPI UV 358 461



Image Courtesy: Carl Zeiss Microscopy GmbH
