GATTA-Cells

 GATTA-Cells  GATTA-Cells

The gattacells series supplies you with high-quality standard cell slides. They are manufactured in close collaboration with the Center for Microscopy and Image Analysis at the University of Zurich. Cell slides of the UZH have proven their outstanding performance by being broadly applied and demonstrated by Leica Microsystems and Olympus Europe.

Ready-to-use gattacell slides contain fixed and stained Cos-7 cells for fluorescence imaging (for instance for wide field, confocal, SIM, STED, or dSTORM).

Currently we are offering three versions:

GATTA-Cells 1C STORM

  • Singlecolor Cos-7 cells
  • Microtubules: Anti-Tubulin with Alexa 647
  • Mounting Medium: Vectashield
  • Recommended for dSTORM applications

GATTA-Cells 4C

  • Multicolor Cos-7 cells displaying 4 colors
  • Nucleus: DAPI
  • Mitochondria: Anti-Tom20 with Oregon Green 488
  • Microtubules: Anti-Tubulin with TMR
  • Actin: SiR

GATTA-Cells 1C

  • Singlecolor Cos-7 cells
  • Nuclear pore complexes: Anti-Nup with Alexa Fluor 555 F(ab´)2
  • Recommended for STED and dSTORM applications

gattacells are embedded in ProLong Diamond and show high photo stability with shelf lifes of at least 6 months (storage at +4 °C).

For dSTORM applications we recommend powerful laser lightsources

product properties of GATTA-Cells

Type GATTA-Cells 4C GATTA-Cells 1C GATTA-Cells 1C STORM
Cell type Cos-7 Cos-7 Cos-7
Available fluorophores SiR, TMR, Oregon Green 488, DAPI Alexa Fluor® 555 Alexa Fluor® 647
Embedding media ProLong Diamond ProLong Diamond Vectashield
Labeling SiR, Anti-Tubulin, Anti-Tom20, Intercalator Anti-Nup Anti-Tubulin
Level Beginner Advanced Advanced
Price 220,-€ 180,-€ 220,-€

Beginner: Samples to check the basic functions of your microscope. Easy to resolve, also for beginners in the field of super-resolution microscopy.

Advanced: Samples to optimize the settings of your microscope. Advanced experience is necessary in order to resolve the nanorulers.

Expert: Samples which demand perfectly aligned microscopes and very experienced users which are able to optimize acquisition and data evaluation.

fluorophore properties

 Fluorophore Our notation
Excitation / nm
Emission / nm
SiR R 652 674
Alexa Fluor 647 R 647 665
Alexa Fluor 555 Y 555 580
TMR Y 543 575
Orgeon Green 488 B 501 526
DAPI UV 358 461

Product sheet

Full size super-resolution Images

References
